Full Wavelength Mecury Curing Lamp
♦ Effective area：
(70mm x 70mm、140mm x 70mm、210mm x 70mm、280mm x 70mm)
♦ Output：1200 mW/cm2
♦ Fan venitation
♦ Low temparature UV filter (STD)
specification
Table (Conveyor velocity v.s. Energy)
【TH2107】
| Lux (mW/cm2) |
Conveyor velocity (m/mins) |
Energy (mJ/cm2) |
| 1200 | 2 | 8640 |
| 1200 | 3 | 5760 |
| 1200 | 4 | 3600 |
| 1200 | 5 | 3456 |
| 1200 | 6 | 2880 |
【TH2807】
| Lux (mW/cm2) |
Conveyor velocity (m/mins) |
Energy (mJ/cm2) |
| 1200 | 2 | 10800 |
| 1200 | 3 | 6720 |
| 1200 | 4 | 5400 |
| 1200 | 5 | 4032 |
| 1200 | 6 | 3360 |
【Lamp Specification】
| Dimension | 300 x 120 x 150 | mm |
| Effective Area | 240 x 80 | mm |
| Output | > 1200 | mW / cm2 |
【Power Specification】
| Dimension | 350 x 300 x 150 | mm |
| Input power | 220 | V |
| Weight | 20 | kg |
| Power | 1200 1600 |
W (TH2107) W (TH2807) |
